16 smc SV1000 solenoid pneumatic air valves + manifold
16 SMC SV1000 Solenoid Pneumatic Air Valves + Manifold
SMC says: "The SV series employs a multi-connector instead of the conventional lead wires for internal manifold wiring. By connecting each block with a connector, changes to manifold stations are greatly simplified."
11pcs. SMC SV1000-series (PN SV1A00-5FU) Valves
* 4 Position Dual Function 3 Port N.C./N.C.
* Pressure range: -100kPa to 0.7MPa
* Response time: <18ms @ 0.5MPa
5pcs. SMC SV1000-series (PN SV1200-5FU) Valves
* 2 Position Double Function
1pcs. SMC SV1000-series Manifold:
* 4mm one-touch quick release fittings for valve ports
* 8mm one-touch quick release inlet & exhaust air ports
