Tennsmith 52" hydraulic sheet metal shear 52H
Tennsmith 52" Hydraulic Sheet metal shear 52H
Up for sale is a Tennsmith 52H hydraulic metal shear in good used condition. Could use a paint job, otherwise everything is in good shape.
The floowing is from Tennsmith's website: Serial number of this unit is 15564
Maximum shearing capacity, mild steel 16 gauge / 1,6mm
Maximum shearing capacity, stainless steel 20 gauge / 1,0mm
Maximum cutting length 52-1/4 in. / 1327mm
Back gauge range 30 in. / 762mm
Front gauge range 37 in. / 940 mm
Floor space, gauges in position 60 x 80 in. / 1524 x 2032 mm
Overall dimensions, less gauges, LxWxH 61 x 25 x 42 in. / 1550 x 915 x 1067 mm
Strokes per minute, full length 60
Maximum operating pressure 1450 psi / 98.6 atmos.
Motor-230/460v, 3 phase, 60Hz, 1745 RPM 3 hp
Amp Draw of 3 phase motor 3hp 8.6 230 volt 3 phase
Motor-230, 1phase, 60Hz, 1725 RPM 3 hp 230 volt 1 phase
Amp Draw of 1 phase motor 3hp 10.7 amps
