Hp E1439A 95 msa/s digitizer with dsp memory & 70MHZ
HP E1439A 95 MSa/s Digitizer with DSP Memory & 70MHz
E1439A - 95 MSa/s Digitizer with DSP, Memory and 70MHz IF input
The Agilent 1439A is ideal for applications in RF signal acquisition, analysis and high resolution ATE. It has a baseband input and a 70 MHz IF input, both with 36 MHz bandwidth. The single-channel 95 MSa/s digitizer combines exceptional spurious-free dynamic range with alias-protected signal conditioning, center-frequency tunable digital filters, and a large signal capture memory, all in a single-wide C-size VXI module. The single difference between the A and B versions is the inclusion of a 2.5Gbit/sec optical front panel data port and TTL trigger input for the 1439B.
* 36 MHz input bandwidth centered at 70 MHz
* -90 dBfs spurious-free dynamic range
* Anti-alias filter and signal conditioning
* 18MB RAM FIFO memory (expandable to 1.2 GB)
* 2.5 Gigabit/second FPDP (E1439B)
* Local bus and VXIbus outputs
* Single-slot, C-size module
With manual and unit only as pictured.
Unit in full working condition pulled from working unit.
