Hp agilent 83480A/100 w 83487A/C26 20 ghz com analyzer
HP Agilent 83480A/100 w 83487A/C26 20 GHz Com Analyzer
Refurbished 83480A Opt 100 with an operational 83487A Opt C26 Optical electrical Plug-In. Exceptional signal analysis capabilities at an extremely low price.
The 83480A Digital Communications Analyzer is used to view waveforms in high-speed digital communications. Industry-standard tests including mask and template tests as well as eye-diagram analysis including extinction ratio are made using easy-to-use, built-in measurements. For measuring optical signals, lightwave receivers are integrated into the instrument to provide highest accuracy and waveform fidelity. With up to 50GHz of bandwidth, the instrument can be used on low-rate tributary signals through 10 Gb/s optical waveforms. In addition to communications analysys, the unit can be used as a general-purpose, high-speed, sampling oscilloscope.
Eye-diagram and pulse waveforms are quickly and conveniently analyzed with a full range of automated statistical measurements.
Standard measurements include:
General Oscilloscope Measurements:
Option 100 = Enhanced Trigger Allows for gated 12GHz triggering.
2.85 GHz 155/622/1063/1250/2488Mbit/s multimode integrated optical reference receiver and 20 GHz electrical channel (750 to 860 nm wavelengths)
* Integrated/calibrated optical channel with highsensitivity
* Automatic/switchable SDH/SONET, Fibre Channel and Gigabit Ethernet filters for compliance testing
