Sumitomo type-66 kit-2 fusion splicer **usa model**
INCLUDES RIBBONIZING TOOL AND CONSUMABLE KIT
** ask about our discounted refurbished units
2 Year USA Factory Warranty !!
WE ARE AN AUTHORIZED SUMITOMO DISTRIBUTOR
(BEWARE OF UNAUTHORIZED 3RD PARTY RESELLERS, CALL SUMITOMO ((***)-775-4237) FOR VERIFICATION)
THIS IS THE USA MODEL AND CAN BE SERVICED AT THE SUMITOMO NORTH CAROLINA FACILITY......
Many Asian units have illegally replaced or modified firmware/ hardware that makes the unit a non-Sumitomo machine,
voiding the Sumitomo warranty and right of repair. It does impact the specifications/ performance ,
(WE TAKE TRADE-INS. IF YOU HAVE ANY EQUIPMENT YOU NO LONGER USE, TAKE IT OFF THE DUSTY SHELFAND TURN IT INTO A CASH TRADE-IN)
The Type-66 TuffCat mass fusion splicer features the industry s first Dual-Automatic- Splice Protection Sleeve Heater System Sumitomo s exclusive patent-pending innovation. The dual heater system s simultaneous operation helps to eliminate squandered time waiting for a single heater system to complete its cycle. Instead, the streamlined splicing process reduces the bottle neck of "heater wait time" by 88%, improving mass splicing efficiency and productivity in the field by 70%.
The TuffCat features an effortless fiber holder system to increase splice repeatability while making the unit easy to use regardless of the operator s experience level. Utilizing precision v-groove alignment, the TuffCat can be used for all types of ribbon and single splicing with an optimum arrangement for ease of use in trunk, aerial, or taut-sheath applications.
Alignment Method - Fixed V-groove
RoHS - Compliant (engineered to be more environmentally friendly)
Fiber Requirement - Silica Glass
Fiber Placement - Fiber Holder System (Unified Holders for Type-25e/Type-66/Type-65)
Coating Diameter: Ribbon 250 m Single: 250 and 900 m
Typical Splice Time - 20 seconds
Typical Splice Loss, Identical Fibers: SMF: 0.04dB, MMF:0.03dB, NZ-DSF: 0.07
Built-In Dual Splice Protection - Dual Independent Splice Protection Sleeve Heater Sleeve Heaters
Heater Cycle Time Heater 1 - 40 seconds Heater 2 - 40 seconds
Arc Test Compensation - Automatic
DC (Battery Operation) : Standard: 70 Splices & Heater Cycles Extended Life: 140 Splices & Heater Cycles
Arc Test - Automatically Compensates for Environmental Conditions
Interface: USB for PC Interface, RCA Jack for External Monitor, 12 Volt DC Output for Accessories
Display Type - 5.6 Inch Color TFT Low Glare High Resolution Color Monitor
Display Positions - Multiple Positional for Front to Back/ Back to Front Work Flow
Selectable Language Options - 18 Language Options including Spanish
Lynx CustomFit Splice-On Connector - Compatible
Splice Data Storage 2000 Splice Points
(CALL 207.221.3154 or email ****@tamge.com for PDF Spec and details)
Features: Dual Independent Splice Protection Sleeve Heaters
Splice-On-Connector Compatible
5.6" Switchable Color Monitor for Front to Back or Back to Front Operation
Fiber Alignment Vibration Clamps
Extended Life Battery: 140 Splices & Heater Cycles per Charge
User-Friendly Menu Selection System with On-Screen Assistance
Spanish Language Option Standard
24-Hour Technical Support via 888-SPLICER
This unit is size, in inches, is 5.9W x 5.9D x 5.9H, with a weight of only 5.95 pounds, the standard battery is enough for 70 splices & heater cycles (140 on Extended battery)
...and it has wind protection of up to 30 MPH
