> 31.5" w 144" l camut tr-2-3000M
TR3000M surface grinde
31.5" w 144" l camut tr-2-3000M
TR3000M surface grinde
31.5" W 144" L Camut TR-2-3000M TR3000M SURFACE GRINDE
31.5" Width 144" Length Camut TR-2-3000M TR3000M SURFACE GRINDER, AUTO IDF, 50 H.P., 39" VERTICA
Table Working Surface:.............. 27.56" X 148"
Maximum Table Travel:...................... 145.7"
to new 22" dia. Wheel:.................... 39.37"
to new 15" dia. Wheel:.................... 42.91"
Wheel Cross Travel: ........................ 31.5"
Wheel Size: ......... 22" Diameter 6" W x 8" Hole
Variable Table Speeds: ............ 3.94 - 98 FPM
Automatic Crossfeed Rates:............ .12" to 3"
Auto Downfeed Rates (10 steps)...... .0002"-.002"
Wheel Speed: ........................... 1152 RPM
Approx. Weight:...................... 68,200 lbs.
Floor Space:........... 360"L x 150" W x 168" High
Automatic Incremental Downfeed of wheel (10 steps)
Automatic Vertical Downfeed may be programmed
with wheel cross reversal or table reversal
(3) 27-1/2" x 39-5/8" EMC Electromagnetic
(4) Wheel Mounts with Grinding Wheels
EXL200 Casven Coolant separator (1200 liter cap.)
15 H.P. Vichers Dual Delivery Pump System
