> 6" w 12" l boyar-schultz 1A surface grinder, hyd. tbl,
6" w 12" l boyar-schultz 1A surface grinder, hyd. tbl,
6" W 12" L Boyar-Schultz 1A SURFACE GRINDER, HYD. Tbl,
6" Width 12" Length Boyar-Schultz 1A SURFACE GRINDER, HYD. TABLE, EMC, BELT DRIVE SPINDLE
6" x 12" BOYAR SCHULTZ "DELUXE"
MODEL: 1A S/N: HY-5599 NEW: 1962
WIDTH & LENGTH GROUND ................... 6" X 12"
MAX. HEIGHT UNDER 7" WHEEL TO TABLE ..... 12-1/8"
LONGITUDINAL TABLE TRAVEL ............... 19-7/8"
LONGITUDINAL TABLE SPEED ................ 0 TO 50' FPM
CROSS FEED TRAVEL ....................... 6-13/16"
CROSS FEED HANDWHEEL .................... 0.001"
VERTICAL HANDWHEEL ...................... 0.0005"
STANDARD GRINDING WHEEL SIZE ....... 7" X 1/2" X 1-1/4"
APPROX. DIMENSIONS ................. 56" X 38" X 63"
APPROX. MACHINE WEIGHT ................. 1,000 Lbs.
3/4 H.P. BOYAR SCHULTZ SUPER-PRECISION BELT DRIVE SPINDLE
6" X 12" "MAGNA-LOCK" MODEL #R-612C FINE-LINE
LONGITUDINAL BAR POLE ELECTRO-MAGNETIC CHUCK
"ELECTRO-MATIC" NEUTROFIER CONTROL WITH ON/OFF SWITCH
BUILT-IN DUST COLLECTOR IN THE BASE
*** MACHINE IS DIRTY, BUT RUNS EXCEPTIONALLY WELL.
HYDRAULICS & SPINDLE IS VERY QUIET. 100% OPERATIONAL,
THIS IS AN EXCELLENT, LOW COST CHOICE ***
