Diamond cx-310A 3-way coaxial antenna so-239 switch
The Diamond CX-310A is a low loss, three position coaxial switch providing very low loss and high isolation. It is rated DC to 800 MHz and can handle up to 1500 watts at HF frequencies. If you have three antennas and you need to connect them to the same transceiver or you need to connect three transceivers to the same antenna then this is the switch you need. The quality is really very high and the turning of the knob is very smooth.
See Specifications below for complete power handing characteristics. This switch utilizes SO-239 jacks for input and output.
* Power 0-30 MHz: 1500 watts
* Power 30-150 MHz: 1000 watts
* Power 150-800 MHz: 500 watts
* Insertion Loss 0-500 MHz: 0.10 dB
* Insertion Loss 500-1000 MHz: 0.15 dB
* Connector: SO-239 (input and outputs)
* Size: 3.3 x 1.5 x 3.75 inches (84x38x95 mm)
