42" tbl 2HP spdl alliant RT2V vertical mill, vari-speed
42" Tbl 2HP Spdl Alliant RT2V VERTICAL MILL, Vari-Speed
42" Table 2HP Spindle Alliant RT2V VERTICAL MILL, Vari-Speed,R-8, Acu-Rite DRO,Chrome
ALLIANT VERTICAL MILLING MACHINE
MODEL: RT2V, S/N: 80112085, NEW: 1986
TABLE SIZE ........................... 9" X 42"
NUMBER OF T-SLOTS .................... 3
MAXIMUM WEIGHT OF WORKPIECE .......... 750 LBS
LONGITUDINAL TABLE TRAVEL ............ 30"
CROSS TRAVEL ......................... 12"
KNEE TRAVEL .......................... 16"
TO TOP OF TABLE ................ 18-1/2" / 2-1/2"
MAX/MIN DIST, CENTERLINE OF SPINDLE
TO FACE OF COLUMN .............. 18-3/4" / 6-3/4"
LEFT & RIGHT ................... 90 DEG
FRONT & BACK ................... 35 DEG
INFINITELY VARIABLE SPEED RANGE ...... 60 - 4,500 RPM
POWER QUILL FEEDS (3) ................ .0015, .003, .006 IPR
SPINDLE TAPER ........................ R-8
MAX COLLET CAPACITY .................. 3/4"
APPROXIMATE WEIGHT ................... 2,250 LBS
ACU-RITE III TWO AXIS DIGITAL READOUT
2 HP 220/440 VOLT 3 PHASE MILLING HEAD
