3 3/4 digi multimeter clamp meter tester ac/dc 34-601
3 3/4 Digi Multimeter Clamp Meter Tester AC/DC
3 3/4 Digi Multimeter Clamp Meter Tester AC/DC 34-601
* USB interface can connect to computer ,Large LCD anoloq bar graph display
* Unit symbol display make the reading clearly, display
* Metallic screen board with strong antimagnetic and anti-interferential function
* Auto power off and alarm when stopped used after 15 minutes
* Full function protection anti-high voltage circuit design
* DC Voltage: 400mV/4V/40V/400V/1000V (0.5%+4)
* AC Voltage: 400mV/4V/40V/400V/750V (0.8%+10)
* DC Current: 400uA/4000uA /40mA/400mA/4A/10A (1.0%+10)
* AC Current: 400uA/4000uA /40mA/400mA/4A/10A (1.5%+10)
* Resistance: 400 /4k /40k /400k /4M /40M (0.8%+4)
* Capacitance: 50nF/500nF/5uF/50uF/100uF (3.5%+8)
* Frequency: 4Hz/40Hz/400Hz/4kHz/40kHz/400kHz/4MHz/30MHz (0.1%+4)
* Temperature: (-20 ~ 1000) (1.0%+5)
* Frequency /duty cycle: 0.1%~99.9%
* AC Frequency response: (40-400)Hz
* Dimensions : 191 93 48 mm
