Aea technology - 140-545 antenna analyzer w/accessories
AEA Technology 140-525 Antenna Analyzer
SEE where your antenna is resonant... Instantly and without question!
AEA s 140-525 Analyzer operates in the UHF/VHF bands, and has a frequency range of 135 -525 MHz. The 140-525 provides graphical plots of VSWR and Return Loss, numerical results, and plot storage.
AEA Technology's 140-525 Analyzer is a graphical antenna analyzer covering 135 to 525 MHz that speeds visualization of VSWR and Return Loss plots. The onscreen plot allows you to quickly determine the best match frequency and the 2:1 bandwidth points. The 140-525 has 15 memories for plot storage and a relative Field Strength meter to determine if there is excessive RF in the testing area.
At 20 ounces, the 140-525 Analyzer is light weight and easily hand held. With the optional Analyst Director Software (Windows 95/98/2000/ME/XP compatible) to interface with your PC, you have endless curve storage and printout capability.
The 140-525 with or without its software is a powerful, yet cost effective, VHF/UHF testing tool set that should be in every Engineer/Technicians tool box.
This listing includes the "Value Bundle" Package for only $80.00 additional:
If you just need the analyzer, see our other listings!
* Simultaneous multiple plot viewing in memory mode.
* SuperTwist display for better contrast and viewing angles.
* Self Test and calibration functions.
* Return Loss and VSWR modes.
* Relative Field strength measurements.
* Optional Windows Analyst Director Software.
* Plot transfer between PC and 140-525.
* Compatible with NiMH and NiCd batteries.
* Battery Saver auto-off and auto-hold functions.
* Display Resolutions: Increments of 10 KHz
* Measurement speed: Single frequency: Several sweeps per second / Normal sweep: < 2 seconds
* Frequency display width: 0 to 500 MHz
* Harmonic and spurious: >40 dB below fundamental
* Output power: >+5 dBm @ 50 ohms
* Serial interface speeds: 9600 to 19.2K baud
* Power requirements: 12 - 16 VDC @ <250 ma or 8 AA batteries (Alkaline or NiMH)
* Antenna connector: Industry standard `N` connector
* Size: 8.5 inch x 4.3 inch x 2.25 inch
* Communications: Serial Port
* Internal Power: 8 AA Alkaline, NiMH or NiCd batteries (optional)
* External Power: 90-240 VAC, 50-60Hz wall adapter (optional)
* High accuracy when checking or tuning antennas.
* Ability to archive and print plots for documentation.
* Lightweight, portable, and battery power capability.
INCLUDES: N to SO-239 Adapter: 0070-1195
* Value Bundle Special (Analyst Director): 5006-1500 - Included in this listing!
* Hard Carrying Case: 6015-1003
* NiMH Batteries (8 AA) & Charger Kit: 0010-0020
* Soft Carrying Case: 6015-1002 - Included in this listing!
* DC Vehicle Adapter: 5001-0250
* Certificate of Calibration: 6000-0402
* DC Extender Cable, 20 ft (6m): 0070-1200
* Adapters, N-to-SMA & Calibration Kit: 6025-0260
* Adapter, N-to-TNC: 0070-1134
* Adapter, N-to-BNC: 0070-1190
