> Aemc OX7102 portable digital oscilloscope scopemeter
Aemc OX7102 portable digital oscilloscope scopemeter
Portable 100 Mhz Digital Oscilloscope
Note: All images show a four channel (OX 7104-C) unit; this unit has only two channels (OX-7102-C).
* Limited Time Offer: Includes the harmonic analyzer software upgrade(2124.71) and recorder function software upgrade(2124.72)!
* Touch Screen, multilanguage
* Internet link with webserver
* 5 kHz, 1.5 KHz and 20 Mhz BWL to reduce noise
* Five complementary tools in one: Oscilloscope, Multimeter, FFT Analyzer, Harmonic Analyzer and Recorder
* Sampling rate 1 GS/s in one-shot and 25 GS/s in ETS with memory depth of 2.5k per channel in oscilloscope mode
* Four independent, 8000-count,TRMS, 50kHz, digital multimeters
* 33 direct command keys and Windows-like menus on screen
* Multi-interface communication connector: RS-232, Centronics and Ethernet with web server
* Resolution 12 Bit ( most other competitors are 8 bit, this gives 16x times more resolution! )
* Built in internet link with web server
* Access the unit from the internet with 10 MB link
* Uses a PowerPC 32 Bit Microprocessor
* 2.5 Mv to 200V per division
* Windows like Math Editor built in
* Probes have hot button controls on the probe itself
* Configure the probe hot buttons then store them in the probe via software
* On-site contractor maintenance industrial or electronic
* Internal plant maintenance
* Installations and start-up
* Research and laboratory engineers or technicians
The Model OX 7104-C s four independent TRMS digital multimeters and optional harmonic analyzer are ideal for industrial maintenance professionals.
Model OX 7104-C includes metallic carrying case, adapter/line charger, NiMH battery pack, 1/10 Probix probe, one BNC Probix adapter, one Probix banana adapter, one set of 4mm banana cords, one crossed Ethernet cord and user manual.
The Model OX 7104-C manages a great variety of sensors (voltage, current, temperature, 0 to 10V, 4 to 20mA, etc) and displays the signals in their original physical magnitude (scale and unit).
Automatic recording of the measure values in memory is performed on all active channels, making possible surveillance of a period lasting from 5 minutes to 24 hours.
* RS232 cable and 1 set red/black test leads
* The harmonic analyzer software upgrade and recorder function software upgrade
Note: All images show a four channel (OX 7104-C) unit; this unit has only
Portable Oscilloscope Model OX7102-C (2x100 MHz, Color - Kit), Model OX7102-C
Color 5 x 7" LCD (115 x 86mm) 320 x 240 CCFL backlighting
Four curves and four references Split screen and full screen modes (tracing zone 110 x 74)
Touch screen - "Windows-like" menus and graphic commands
Five complete languages, menus and on-line help (English, French, German, Spanish, Italian)
Maximum Permanent Input Voltage
600V Cat. III Derating -20dB/decade at 100kHz
16 ranges from 2.5mV to 200V/div
1 / 10 / 100 / 1 000 or scaling to any value Definition of the measurement unit
35 ranges from 1ns/div to 200s/div
Auto, trigger, single, Auto 50%
Front, pulse or delay (20ns/340s), count (2/16384) or TV (525 or 625 lines)
AC, DC, HFR, LFR, noise reduction Hold-off adjustable from 40ns to 1s
0.6 div to 1KHz / 1.5 div to 150MHz
25 GS/s in ETS - 1 GS/s in one-shot (on each channel)
TRC approx. 10kB, TXT approx. 20kB
Envelope mode (Factors from 2 to 64)
XY Mode Between two from the four curves math functions and cursors
Complete autoset at less than 3s, with recognition of channels Frequency : > 30Hz
Analyzer and Math Functions FT, + , - , x , / - Editor of mathematical functions
Two or three cursors : V and T simultaneous or Phase Resolution 12 bits, display four digits
18 level or time measurements, phase measurements Resolution : 12 bits, display four digits
From 400.0mV to 600.0VRMS or 800.0VDC - Accuracy VDC 0.5 % R+ 5D bandwidth 50kHz
80.00 to 32.00M - Precision 0.5 % R+ 5D - Rapid 10-ms continuity test
5.000nF to 50.00mF/Frequency 200.0MHz - Diode test 3.3V
Conditional on thresholds or windows Normal or "50-faults" acquisition
Timestamped graphic recording, conversion and units of physical quantities, measurement using cursors and search for events, standard file format usable in spreadsheets (.TXT)
Span Even or odd orders up to 31, or first 16 orders
Permanent display: total RMS value and harmonic factor
Order selected: % F, phase, freq, VRMS
Memories Unlimited - .CFG file size approx. 1kB
Ethernet Network Printing Standard
11 black and white or color drivers - IBM Proprinter, Epson ESC/P, Canon HP PCL, Seiko DPU411
Postscript Image files - .BMP 10kB, .GIF approx. 5kB (storage in memory transfer by RS-232 or Ethernet)
Local via Ethernet 10 MB or RS 232 (option) - Remote via 10 MB Ethernet and web server
Sx-Metro application software for PC (option)
9.6V/3.8 A/h battery pack - Approx. 4h between charges - Adjustable power-saving switching
98-254V / 47-63Hz - Fast charge in 2 hours (oscilloscope off)
10.25 x 7.25 x 2" (261 x 185 x 53mm)
4.2 lbs (1.9kg with batteries)
