> New tjernlund SS1-c oil sidewall vent system SS1C
New tjernlund SS1-c oil sidewall vent system SS1C
NEW TJERNLUND SS1-C SIDESHOT VENTING SYSTEM
SIDESHOT SERIES MODELS SS1 & SS2
The SideShot models SS1 and SS2 SideWall Vent Systems include the UC1 Universal Control for increased safety, performance and reliability. Designed for oil fired heating equipment or a deluxe gas vent system. Patented vent termination propels flue gases at high velocities away from the building exterior, a necessity when venting oil fired equipment. Both models can be installed with zero clearance to combustible materials and have stainless steel construction in critical areas. Factory wired safety and operating controls allow for simple interlock with any burner. The new model SS2 features a self-cleaning stainless steel, backward inclined impeller and sealed ball bearing motor for virtually maintenance free installations. Ultra-fine draft adjustment and slide-out access to all internal components. Easy multiple appliance interlocks with our MAC Series multiple appliance controls.
SIDESHOT MODEL SS1 APPLICATION TABLES
Verify that the total BTU/hr input of the heating appliance(s) fall within the proper category listed below. Please note the capacity differs between the SS1, SS1C and SS2. To determine equivalent feet, add the total length of straight vent pipe plus 10 feet for each 90 degree elbow and 5 feet for each 45 degree elbow. Vent runs over 15 linear feet should use an approved, insulated vent connector to prevent problems related to condensation. Multiple appliance interlocks require the use of our MAC-Series Multiple Appliance Controls.
The SS1 & SS1C feature a bottom or rear vent connection. The inlet collar accepts any brand or type of 6" diameter vent pipe.
(For larger residential and commercial applications)
Note: The SS1 requires an 8"H x 8 3/8"W opening through the wall
