> New fast variable vacuum capacitor 10-35PF/10KV in box
New fast variable vacuum capacitor 10-35PF/10KV in box
KP1-21W Vacuum Variable Capacitor
http://qro-parts.com/images/kp1-21v/1560.jpg
It is developed for a fast load tune in mobile transmitters up to 5-10kW and in "Small Loop-STEALTH Antenna" to 10kW projects.
http://qro-parts.com/images/kp1-21v/1561.jpg
Perfect for tuning of any Magnetic Loop Antennas (up to 10kW) or any Great Antenna design.
http://qro-parts.com/images/kp1-21v/1564.jpg
FREQUENCY RANGE: before 100 MHz
Military TEST Voltage: 25kV at 30MHz
MAX. WORKING Voltage: 20kV at 30MHz
Temperature of work *C: -50 +150
Dimensions: D 138mm x H 218 mm (5,15"D x 8,6") w/o shaft
Tuning shaft: 12,5x20mm (0,5"D x 0,79")
Material of movinging electrode: special chemical clean copper.
Possible work without load.Possible work at ground. Possible redouble the peak voltage to 40kV
This sale is for ONE KP1-21 10-35 pF/10kV Fast Tune vacuum variable capacitor Sealed in the factory box. Really NEW !!!
