Air-over-hydraulic 5.5-ton press air-hydraulics c-300
Air-Over-Hydraulic 5.5-Ton Press Air-Hydraulics C-300
Air-Hydraulics C-300 Specifications and Features:
* Output power: 110x input air pressure (theoretical max. 11,000lbs)
* Power requirement: 120VAC plus 100PSI air
* WITH adjustable output power
* WITH up/down speed controls
* WITH anti tie-down two-handed operator controls
* WITH upgraded Omron SYSMAC CPM2A PLC and NT2S HMI
* Overall dimensions (approx.) 67" x 51" x 67"H
* Slide table dimensions: 28" x 15" (aluminum top plate is 21" long)
* Max. work area: 17-1/2" x 24-1/2"
* Current Ram Up/Down Travel (it's adjustable): 5-1/8"
* Travel Specification: 6-1/8" to 4-1/8"
* WITH leveling feet (or floor bolt-down holes if feet are removed)
