1000X cordless student compound microscope w int.dynamo
Crank Student Compound Microscope
This versatile and value priced microscope is designed for K-12 students. The CM304H microscope is equipped with four high quality DIN standard objectives and a widefield WF10X/18 eyepiece with built-in scale and pointer. Green Friendly 3W LED technology is used in the illumination system. The cool light provide a safe and bright illumination.
The most interstering feature of this microscope is the internal dynamo, which is operated by a hand crank. So this microscope can work anywhere and any long time. No more worry about the power outlet not available or power outage.
Widefield WF10X/18 with built-in pointer and scale, secured by a set screw
Achromatic DIN standard 4X, 10X, 40X (spring, sealed), 100X (spring, oil)
Revolving, quadruple, reverse facing
Mechanical stage, range 25mm x 70 mm, dimension 114mm X 125mm
Spiral Abbe NA1.25 w/ iris diaphragm, attached on the stage
Iris diaphragm, attached on the condenser
Separate coarse and fine focusing knobs on both sides, built-in slip clutch, adjustable rack stop, tension adjustment with wrench
Transmitted, 3W LED light (equivalent to 30W halogen), brightness adjustable
3 AA rechargeable batteries, 1.2V 2450mAh
AC adapter/charger (UL, CE and FC approved)
10 " x 5-7/8" x 14" (25.4 cm x 15 cm x 35.5 cm)
* Objectives: DIN 4X, 10X, 40X and 100X (installed)
* 3 rechargeable batteries (installed)
* Plan, semi-plan objectives
Click the button above to view the list of accessories compatible with this product CM304H
