Galil dmc-4040 ethernet RS232 4-axis motion controller
Galil DMC-4040 Ethernet RS232 4-Axis Motion Controller
Only what is pictured is included.
* (1) New Galil DMC-4040 Ethernet RS232 4-Axis Motion Controller
* (1) New Galil Product Manuals CD
Description: The DMC-4040 motion controller is Galil's highest performance, stand-alone motion controller. It belongs to Galil's latest generation motion controller family: the Accelera Series, which accepts encoder inputs up to 22 MHz, provides servo update rates as high as 32 kHz, and processes commands as fast as 40 microseconds-10 times the speed of prior generation controllers.
The DMC-4040 is a full-featured motion controller packaged with optional multi-axis drives in a compact, metal enclosure. The unit operates stand-alone or interfaces to a PC with Ethernet 10/100Base-T or RS232. The controller includes optically isolated I/O, high-power outputs capable of driving brakes or relays, and analog inputs for interfacing to analog sensors. The DMC-4040 controller and drive unit accepts power from a single 20-80 VDC source. The DMC-4040 is available in one through eight-axis formats, and each axis is user-configurable for stepper or servo motor operation.
With a powerful RISC processor, the DMC-4040 controllers provide such advanced features as PID compensation with velocity and acceleration feedforward, program memory with multitasking for simultaneously running eight applications programs, and uncommitted I/O for synchronizing motion with external events. Modes of motion include point-to-point positioning, position tracking, jogging, linear and circular interpolation, contouring, electronic gearing and ecam.
Like all Galil controllers, programming the DMC-4040 is simplified with two-letter, intuitive commands and a full set of software tools such as GalilTools for servo tuning and analysis (software is not included).
