New fluke 17B lcd digital multimeter meter high quality
NWE FLUKE 17B F17B LCD Digital Multimeter Meter Multiple functions
Multiple functions with Auto / Manal ranges.
Large LCD display, 4,000 Counts update 3/sec
Main Measurements : Frequency, Temperature, AC/DC A-V-Ohm , capacitance, Diode & Continuity , duty cycle
Both Auto range and Manual range Selectable
Overrange protection for all ranges
Polarity Indication : Indicates negative polarity
Sleep Mode / Auto Power off / Low Battery Indication
Continuity Test with Alert
Temperature : -55C to 400C
Capacitance : 0.01nF to 100uF
AC Volts : 0.1mV to 1,000V
DC Volts : 0.1mV to 1,000V
Resistance : 0.1 ohm to 40Mohm
Duty Cycle : 0.1% to 99.9%
Frequency : 50 / 500 / 5K /50K / 100KHz , +/- 0.1% + 3
Temperature : -55C to 400C , 2% to 9 % +/- 2C
Capacitance : 50nF / 200nF / 2uF / 20uF / 200uF / 20mF , +/-2% +5
DC Volt : 400mV / 4V / 40V / 400V / 1000V , +/-1.0% + 10
AC Volt : 400mV / 4V / 40V / 400V / 1000V, +/- 3.0% + 3
DC Current : 400uA / 4,000uA / 40mA / 400mA / 4A / 10A , +/- 1.5% + 3
AC Current : 400uA / 4,000uA / 40mA / 400mA / 4A / 10A , +/- 1.5% + 3
Resistance : 400 / 4K / 40K / 400K / 4M / 40M Ohm , +/- 0.5% + 3
Duty Cycle : 0.1% to 99.9% , +/-1%
Power Supply : 2 x AA 1.5V Battery
Dimension : 180 x 89 x 51.5mm
