Eos VLT100-4000 quad dc 100W mini power supply
EOS VLT100-4000 Quad DC 100W Mini Power Supply
EOS Model VLT100-4000 Specifications:
* Input: 90-264VAC 47-63Hz 2.2A(max)
* Load regulation: 0.5% Output 1, 5% Outputs 2,3, and 4
* MTBF >200,000hrs, MIL-HDBK-217F
* Agency approvals: CE marked, VDE, UL, cUL
* 100W convection-cooled rating
* Low conducted and radiated noise
* Power Good and Power Fails signals
EOS brand VLT100 power supplies offer a full 100-watts convection cooling, 6.7W per cu. inch power density and ultra high efficiency at over 85%. Fitted in a slim line 5.0 x3.04 x1.073 package the VLT100 is the ideal AC/DC power solution for data networking, industrial and multimedia applications.
