New amp hydraulic hand crimping tool 59975-1
The manufacturer number is 59975-1.
It is designed for crimping AMP SOLISTRAND terminals and splices on AWG 8 through AWG 2 wire. It has a stationary lever and a movable lever. These levers are compressed to pump hydraulic fluid behind the ram, moving it forward and thereby closing the dies.
After the crimping is complete, a trigger on the movable lever is squeezed to depress the release plunger. The moving die retracts to its original position, completing the crimping cycle.
To select the die, press head latch and open crimping head and pull back the die latch and turn thumb knob until desired die size appears.
I appreciate your interest. Please email me with any questions.
