Sheldon 13" m series swing lathe manual, parts list
M Series Lathes-13-inch Swing Parts List
This is a reproduction, not a photocopy, of an original Sheldon M Series Lathes-13" Swing Parts List. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams. This is a very good manual that covers everything stated below in the contents.
Headstock Assembly...............................................2
Tailstock Assembly..................................................3
End Gearing Assembly.............................................4
Reverse Plate Assembly...........................................5
Gear Box Assembly.................................................6
Bed Unit Assembly..................................................7
Pedestal Assembly...................................................8
Uncrating Instructions...............................................9
Leveling Instructions...............................................10
Oiling Instructions...................................................11
Replacing V-Belts..................................................12
Serial Number Location.........................................13
Metric Attachment.................................................14
Metric Instructions.................................................15
W-Drive Assembly.........................................16&17
U-Drive Assembly.................................................18
E-Drive Assembly..................................................19
Apron Assembly....................................................20
Compound Assembly.............................................21
Carriage Assembly.................................................22
