Oztec 2 - 3/4" rubber vibrator head
Oztec HR275 OZ - Oztec 2 - 3/4
Oztec 2 - 3/4" Rubber Vibrator Head
OUR SKU# OZT1018 MPN: HR275 OZ
Epoxy coated rebar presents a particularly troublesome problem. Steel heads act like an electric hammer, striking any rebar or forms they contact, over 10,000 times per minute, with a force from hundreds to over 2,000 pounds per blow. Contact with a steel vibrator head of as little as one second can chip enough coating to subject the steel to deep rust. Oztec's patented High Efficiency ''RubberHeadTM'' vibrator head not only meets DOT non-metal head specifications for protecting coated rebar and expensive forms, but exhibit some very special and unique properties. This 2 - 3/4'' Rubber Vibrator Head is highly efficient, this ''RubberHead'' urethane dimpled construction sends strong shock waves off the entire length of the head, with a larger radius of action, producing denser concrete with less voids to patch.
* Will protect epoxy coated rebar and expensive forms
* Urethane protective coating
* Patented high efficiency vibration vector design
* Is outstanding in low slump (to ''0'' slump) concrete
* Essential in large pours of very stiff concrete
* Makes concrete denser with less voids to patch
* Vibrates @ 12,000vpm, never drops below 10,500vpm when lowered deep into low slump concrete
* Is an absolute must for Architectural concrete where cosmetic surfaces are essential.
* All Oztec vibrators meet or exceed ACI specification # 309
* Centrifugal Force: 2100 lbs
* Compaction Rate: 25 - 35 cu.yds/hr
* Overall Dimensions: 2 - 3/4'' x 14''
Oztec HR275 OZ - Oztec 2 - 3/4" Rubber Vibrator Head
