Garland GFE60-6R24RS range, 60" wide, 6 burners (33,000
Range, 60" Wide, 6 Burners (33,000 BTU), 24" Raised Griddle Broiler Right, One Oven (38,000 BTU), One Storage Base, Electronic Pilot Ignition, Starfi
GFE Starfire Pro Series Restaurant Range, gas, 60"W, (6) 33,000 BTU open burners, with cast iron top & ring grates, electric pilot ignition, 24" raised griddle/broiler (std on right), (1) standard ovens w/3 position rack guides w/oven rack, (1) storage base, stainless steel front, sides, plate rail and 10" low profile back guard, 6" s/s legs with adjustable feet, 227,000 BTU, CSA, NSF (Garland)
* Gas restaurant series range with large capacity (standard) oven.
* 59 1/16" wide and 27 1/4" deep work top surfaces.
* Total flame failure protection for all burners.
* Stainless steel front, sides and 5" wide front rail.
* Six Starfire-Pro 2 piece, 26,000 Btuh/7.61 kW, cast open burners set in split cast iron ergonomic grates.
* Porcelain oven interior with ribbed oven bottom and door. "Keep cool" oven door handle.
* Heavy cast iron "H" 38,000 Btuh/11.13 kW (natural gas) oven burner controlled by even bake, fast recovery snap action modulating oven thermostat.
* Available with convection oven(s) (spark ignition models only) or storage base in lieu of standard oven.
* Flame failure protection: all burners
* Spark ignition on all concealed burners (open top burners manual ignition)
* Large 27" (686mm) work top surface
* Stainless steel 5" (127mm) plate rai
* 6" adj. stainless steel legs
* Gas regulator 1" NPT rear gas connection
* Electric spark ignition on all burners, requiring single phase 115V 60Hz
* Ergonomic split cast iron top ring grates
* 26,000 Btuh/7.61 kW 2 piece cast iron Starfire- Pro open top burner
* 24" (610mm) raised griddle/broiler section W/ 3 cast iron burners each
* rated 11,000 Btuh/3.22 kW, w/one manual hi/lo valve per burner
* 5/8" (15mm) thick steel griddle plate,
* 23" (584mm) working depth surface
* 4-1/4" 108(mm) wide grease trough
* 38,000 Btuh/ 11.13 kW cast iron "H" style oven burner
* Snap action modulating oven thermostat low to 500 F
